🛡️ INVISIX.IO: AdBlock + VPN Ready-to-Go

Welcome! This project effectively allows you to have an ad blocker for your entire home network and a private VPN to access it from outside, all on a single Raspberry Pi.

🚫 Goodbye Ads: Browse faster and without distractions. 🔒 Private VPN Included: Connect to your home securely from your mobile device when you are away (4G/5G) without opening any ports. ✅ Easy & Fast Setup: Up & running in 10 minutes by non-technical users. Tested!

---

📦 What do you need?

1. 🍓 Raspberry Pi 4 (or higher).
2. 💾 MicroSD Card (minimum 8GB).
3. 🔌 Ethernet Cable.
4. ⚡ USB-C Power Supply for the Pi.

🚀 Installation Guide ("Step-by-Step")

Step 1: Download and Flash 💾

1. Download the invisix-distro.img file we generated.
2. Download and install Raspberry Pi Imager.
3. Open the program:
   • Raspberry Pi Device: Choose your model (Raspberry Pi 4).
   • Operating System: Scroll to the bottom, choose "Use Custom" and select the invisix-distro.img file.
   • Storage: Choose your SD card.
   • CLICK NEXT AND THEN "NO" TO EDIT SETTINGS. (We have already configured them).
   • Click Write and wait for it to finish.

Step 2: Configure VPN (Magic!) ✨

If you don't want VPN, skip this step.

1. Go to Tailscale.com and create a free account (you can use Google/Microsoft).
2. Go to Settings > Keys.
3. "Generate auth key" button.
4. Copy the long code starting with tskey-....
5. On your computer:
   • Open the SD card you just flashed (it will appear as a disk named bootfs).
   • Create a new text file named tailscale-auth.key.
   • Paste your tskey-... key inside.
   • Save and close.
6. Eject the SD card.

Step 3: Connect and Power On 🔌

1. Insert the SD card into the Raspberry Pi.
2. Connect the Internet cable (from Router to Pi).
3. Connect the power cable.
4. Wait 5 minutes. ⏳
   • The Pi will detect your network, auto-configure itself, and connect to the VPN.

Step 4: Configure your Router (The only manual step) ⚙️

For Pi-hole to work, your router needs to know it exists.

1. Log in to your router's web interface (usually http://192.168.1.1 or http://192.168.0.1).
2. Find the "DHCP" or "Local Network" section.
3. Find the list of connected devices and look for the one named raspberrypi.
4. Enable the "DHCP Reservation" or "Static Lease" option for that device.
5. Copy that IP (example: 192.168.1.50).
6. In the router's DNS configuration, set that IP (192.168.1.50) as the Primary DNS.

✅ Done!

How do I use it?

At Home (Wi-Fi): You don't have to do anything. Ads will disappear from your phones, tablets, and computers automatically.

Away from Home (4G / Public Wi-Fi):

1. Install the Tailscale app on your phone.
2. Log in with your account.
3. Toggle the "Active" switch.
4. Done! You are browsing securely through your home connection and without ads.

Control Panel

To see how many ads you've blocked:

• Web: http://<YOUR-OBTAINED-IP>/admin
• Password: admin
